BenQ Board Essential Series RE7504FV 1.9 m (75") 4K UHD Interactive Display

BenQ Board RE04FV

The ultimate collaboration solution

The BenQ Board RE04FV streamlines your meeting spaces by combining all the presentation and collaboration tools you need into one powerful smart solution.

Present Conveniently share and control your screen for engaging interactive presentations. Crisp visuals and room-filling sound help you command attention.

Meet With its built-in conferencing features and wide array of supported apps, the RE04FV is compatible with any UCaaS solution.

Ideate Use the web or your preferred apps with a flexible, feature-rich whiteboard that allows you to explore and refine your ideas.

Co-create The smart board’s expandable canvas, 40 touch points, and session saving options give your teams unlimited space to collaborate freely.

Certified Google EDLA

With Google EDLA (Enterprise Device Licensing Agreement) certification, the RE04FV gives you access to an expansive library of corporate apps as well as official Google tools and services that allow you to work directly from the board.

Expand your computing power

Plug in a Windows slot-in PC to use specialized apps directly from your BenQ Board.

Efficiently manage your boards and accounts

BenQ Boards come with a complete suite of device and account management tools for administrators. Conveniently register new devices, configure settings, and regulate user access from the cloud.

Onboarding

Quickly register all your boards just by uploading a CSV file or scanning their QR or barcodes.

Policy Management

Conveniently create and deploy device, security, and app policies for all your boards on one console.

Usage Analytics

Generate comprehensive device analytics for data-driven IT management decisions.

Built for security

The RE04FV has holistic data privacy and security options that help protect your organization against potential threats.

Secure SSO

Account separation and single sign-on ensure that user preferences, files, as well as browsing and app data can only be accessed by their rightful owners.

User list syncing

Directory service syncing ensures that only registered users can access the boards.

*BenQ Boards support Microsoft Entra ID, Google Workspace, and other LDAP or SAML-based identity providers.

Update management

Official and timely firmware and app updates from Google, BenQ, and partner developers provide stability and keep the boards protected against vulnerabilities.

One-tap login

NFC login protects privacy by eliminating the need to manually enter user credentials every time.

Application control

Install and update apps remotely while blocking the use of unauthorized apps on all boards.

Antimalware measures

Google Play Protect and Safe Browsing help scan for malware and other threats.

A greener solution for sustainable collaboration

The RE04FV is designed with environmental sustainability and user health in mind.

Panel

Connectivity

• Screen size:75''
• Panel type: IPS
• Active area:1649.7 × 927.9 mm
• Aspect ratio:16:9
• Resolution: UHD 3840 × 2160 pixels
• Response time: 8ms
• Color depth:10-bit
• Orientation: Landscape
• Operation hours:18 hours / 7 days
• Panel brightness (typical):450 nits
• Contrast ratio (typical):1200:1
• Dynamic contrast ratio:30,000:1
• Color gamut:72% NTSC
• Backlight life (typical): 50,000hrs

• HDMI (in | out): 3 × HDMI 2.0 | 1 × HDMI 2.0
• DisplayPort: 1 × 1.2a
• USB-A: 2 × 2.0 + 2 × 3.0
• USB-C:1 × 2.0 + 1 × 3.0 (PD 65 W)
• USB-B (for touch): 2 × 2.0
• 3.5 mm Line in (1): PC Audio × 1
• VGA: 1
• 3.5 mm Line out: Earphone × 1
• OPS slot (for slot-in PC): 1
• Micro SD reader: ×1 (Expandable up to 512GB)
• S/PDIF out: 0 | 1 (optical)
• Ethernet: 10 / 100 / 1000 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2
• 3.5 mm Line in (2): Mic × 1
• RS-232:1

Glass

Touch screen

• Germ-resistant technology: Availability dependent on region
• Anti-glare: Yes
• Hardness:9H tempered

• Touch technology: Precision IR
• Touch points: up to 40
• Touch response time: < 5ms

System

Built-in peripherals

• GPU:G52 MP8
• CPU:A73 × 4 + A53 × 4
• Memory | Storage:8 GB | 128 GB (depends on region)
• OS:Android 14.0 (EDLA)

• NFC sensor:Yes
• Ambient light sensor:Yes
• IR sensor:Yes
• Microphone:8-microphone array (range: up to 8 m | 26ft)
• Speaker:2 × 20 W (max)
• Camera:1

Power

Physical

• ENERGY STAR®:Yes
• Power:AC 100-240V 50/60Hz
• Standby power consumption:<0.5 W
• Typical power consumption:73.9 W

• Dimensions (W x H x D):1716.5 × 1045.4 × 87.7 mm (67.6 × 41.2 × 3.5 inch)
• Shipping dimensions (W x H x D):1860.0 × 1125.0 × 185.0 mm (73.2 × 44.3 × 7.3 inch)
• Weight (product I shipping):49.6 kg | 57 kg (109.4 lbs | 125.7 lbs)
• Mount (screws):VESA 800 × 600 mm ( 4 × M8 × 25L)

Environment

Software

• Operating temperature:0°C ~ 40°C | 32°F ~ 104°F
• Storage temperature:-10°C ~ 60°C | 14°F ~ 140°F
• Storage humidity:10% ~ 80% RH non-condensing
• Operating humidity:20% ~ 80% RH non-condensing

• Whiteboarding: EZWrite 6.0
• Wireless screen sharing: InstaShare 2
• Device management: DMS
• Account management: AMS
• Flicker Free: Yes
• Quick access tool: Floating Tool
• Broadcast system: X-Sign Broadcast
• Low Blue Light: Yes

Accessories

• Cables:1 × VGA (3 m | 9.8 ft), 1 × HDMI (3 m | 9.8 ft), 1 × USB-B for touch (3 m | 9.8 ft), 1 × USB-C (1.5 m | 4.9 ft)
• Wall mount:1
• Pen:2
• Remote control:1
