BenQ RP6504

Google Enterprise Partner

The new EDLA-certified BenQ Board Pro RP04 gives the best possible meeting room experience by combining the power of BenQ software and hardware with official Google service

What is EDLA?

EDLA stands for Enterprise Devices Licensing Agreement, a new program that Google introduced at the end of 2022. It’s designed to help solutions providers offer devices with built-in Google Mobile Services.

Enterprise-Grade Security
to Defend Hybrid Workplaces

Through the Google Play Protect service, Play Protect checks apps for suspicious behaviour. It also prevents you from downloading potentially harmful apps to your devices and even scans and removes previously installed apps that exhibit malicious behaviour.

Access Files From Google Drive

Panel

Connectivity

• Screen size:65''
• Panel type :IPS
• Active area:1428.5 × 803.5 mm
• Aspect ratio:16:9
• Resolution :UHD 3840 × 2160 pixels
• Response time: 8ms
• Color depth:10-bit
• Orientation :Landscape
• Operation hours:18 hours / 7 days
• Panel brightness (typical):450 nits
• Contrast ratio (typical):1200:1
• Dynamic contrast ratio:50,000:1
• Color gamut:72% NTSC
• Backlight life (typical):50,000hrs

• HDMI (in | out):4 × HDMI 2.0 | 1 × HDMI 2.0
• DisplayPort:1 × 1.2a
• USB-A:7 × 3.0, 1 × 2.0
• USB-C:1 × 3.0 (PD 100 W), 2 × 3.0, 1 × 2.0 (PD 65 W)
• USB-B (for touch):3 × 3.0
• 3.5 mm Line in (1):Mic × 1
• VGA:1
• 3.5 mm Line out :Earphone × 1
• OPS slot (for slot-in PC):1
• Wi-Fi :Wi-Fi 6
• Bluetooth®:Bluetooth 5.2
• S/PDIF out:1 (optical)
• Ethernet:2
• 3.5 mm Line in (2):PC Audio × 1
• RS-232:1

Glass

Touch screen

• Germ-resistant technology :Nano-ionic silver
• Anti-glare :Yes
• Hardness:9H tempered

• Touch technology :Ultra Precision IR
• Touch points :up to 50
• Touch response time:< 2.5ms

System

Power

• GPU :Arm Mali-G57 MC5
• CPU :Arm Cortex-A78 × 4 + A55 × 4
• Memory | Storage :8GB | 128GB
• OS :Android 15.0

• ENERGY STAR®:Yes
• Power :AC 100-240V 50/60Hz
• Standby power consumption:<0.5 W
• Typical power consumption:95.0 W

Built-in peripherals

Physical

• NFC sensor :Yes
• Ambient light sensor :Yes
• IR sensor :Yes
• Motion sensor :Yes
• Microphone:8-microphone array (range: up to 8 m | 26ft)
• Speaker:2 × 20 W (max)
• Air sensor :CO₂, PM₂.₅, PM₁₀, TVOC, CH₂O, temperature, humidity
• Subwoofer:1 × 16 W
• Air Ionizer :Yes

• Dimensions (W x H x D):1488.4 × 937.6 × 117.7 mm (58.6 × 36.9 × 4.6 inch)
• Shipping dimensions (W x H x D):1628 × 1024 × 208 mm (64.1 × 40.3 × 8.2 inch)
• Weight (product I shipping):40.6 kg | 47.8 kg (89.5 lbs | 105.4 lbs)
• Mount (screws):VESA 600 × 400 mm (4 × M8 × 25L)
• Pen Tray:Yes

Environment

Software

• Operating temperature:0°C ~ 40°C | 32°F ~ 104°F
• Storage temperature:-20°C ~ 60°C | -4°F ~ 140°F
• Storage humidity:10% ~ 90% RH non-condensing
• Operating humidity:10% ~ 90% RH non-condensing

• Whiteboarding :EZWrite 6.0
• Wireless screen sharing :InstaShare 2
• Device management :DMS
• Account management :AMS
• Flicker Free :Yes
• Quick access tool :Floating Tool
• Broadcast system :X-Sign Broadcast
• Low Blue Light: Yes

Accessories

Main Specifications

• Cables:1 × VGA (3 m | 9.8 ft), 1 × HDMI (3 m | 9.8 ft), 1 × USB-B for touch (3 m | 9.8 ft), 1 × USB-C (1.5 m | 4.9 ft)
• Wall mount:1
• Pen:2
• Remote control:1

• Display sizes:165cm
